25
CHILD RESTRAINT OVERVIEW
SELECT FORWARD FACING POSITION
FORWARD-FACING:
22 – 65 lbs (10 – 29.4 kg)
Use FORWARD-FACING with children:
•Who are at least one year old.
•Who weigh between 22 and 65 lbs
(10 –29.4 kg).
•Who are 49” (1245 mm) tall or less OR when the
top of the ears are below the top of the Head Rest.
•When Harness Straps can be positioned at or
above the child’s shoulders*.
See Harness Height
Adjustment on page 80.
FORWARD - FACING
NO LATCH
22 lbs. 40 lbs. 65 lbs.
(10 kg) (18 kg) (29.4 kg)
*
