CHIEF MTM1U - Tools Required for Installation; Parts Identification

MSM1U / MTM1U / LSM1U / LTM1U Installation Instructions
6
TOOLS REQUIRED FOR INSTALLATION
PARTS
7/32" (5.5mm) Wood Stud
#2
3/8" (9.5mm) Concrete
1/8"
(included)
3/16" x 10"
(included)
C (4)
E (4)
A (4)
M4x12mm
B (4)
M4x20mm
M4x25mm
D (4)
M5x12mm
M5x20mm
F (4)
M5x25mm
G (4)
M6x12mm
H (4)
M6x20mm
[Interface brackets]
Universal Hardware Kit
I (4)
M6x25mm
K (4)
J (4)
M8x12mm
M8x20mm
L (4)
M8x30mm
MA (8)
[Nesting
MB (4)
[Universal washer]
Wall Mounting Hardware Kit
N (4)
5/16 x 2-1/2"
P (4)
UX10x60mm
Q (4)
[Slotted
washer]
X (4)
[Wall cover]
MSM1/LSM1 Mount Hardware
R (1)
1/8"
S (1)
3/16"
T (4)
1/4-20 x 3/4"
U (2)
3/8-16 x 3/4"
MTM1/LTM1 Mount Hardware
R (1)
1/8"
S (1)
3/16"
T (4)
1/4-20 x 3/4"
U (2)
3/8-16 x 3/4"
V (2)
1/4-20 x 1"
W (2)
1/4-20
Y (1)
Z (1)
[left]
[right]
AA (1)
BB (1)
[left]
[right]
LTM1U
[Interface brackets]
CC (1)
[MSM1U/MTM1U
mount]
CC (1)
[LSM1U/LTM1U
mount]
OR
spacer]
[Included in hardware box]
[Included in hardware box]
[Included in hardware box]
MSM1U
Y (1)
Z (1)
[left]
[right]
LSM1U
AA (1)
[left]
BB (1)
[right]
MTM1U
