Chigo CS-25V1A-H1; CS-35V1A-E2; CS-50V9A-S; CS-70V9A-T User Manual

10
Heating Capacity (KW)---Run Model,230V,Indoor fan at high speed
ID COIL ENTERING AIR DB TEMPERATURE [
0
F]
OD COILENTERING
AIR DB/WB TEM
PERATU RE[
0
F]
DATA 59 68 77
TC 8960 8260 7700
5/3
PI 0.66 0.73 0.80
TC 9940 9240 8680
14/10
PI 0.80 0.87 0.95
TC 10640 10080 9380
20/18
PI 0.91 0.97 1.04
TC 11060 10500 9800
30/28
PI 0.96 1.02 1.08
TC 11340 10640 10080
36/34
PI 0.99 1.06 1.12
TC 14560 14000 13440
45/43
PI 1.04 1.11 1.18
TC 15400 14840 14140
50/48
PI 1.11 1.18 1.25
TC 16240 15680 14980
59/54
PI 1.16 1.22 1.30
TC 85 - 105 % of nominal
59~75
(Protection Range)
PI 80 - 120 % of nominal
LEGEND
TC – Total Cooling Capacity, BTU SC – Sensible Capacity, BTU PI – Power Input, kW
WB – Wet Bulb Temp., (
0
F) DB – Dry Bulb Temp., (
0
F) ID – Indoor OD – Outdoor
