E10
Terminal
number
External signal
input 6 points
External signal
output 6 points
DI DO
DI DO
DI DO
DI DO
DI DO
DI
DO
COM
COM
Terminal
number
Communications
RS232C(COM1)
+
Communications
RS232C(COM2)
+
External digital
input 1 point
Communications
RS232C(COM1)
+
Communications
RS422A(COM2)
+
External digital
input 1 point
COM１
RD１
COM１
RD１
SD１ SD１
SG１ SG１
COM２
RD２
COM２
RDA２
SD２ RDB２
SG２ SDA２
SDB２
DI DI
COM COM
Terminal
number
Communications
RS232C(COM1)
+
Communications
RS485(COM2)
+
External digital
input 1 point
Communications
RS485(COM1)
+
Communications
RS232C(COM2)
+
External digital
input 1 point
COM1
RD1
COM1
SA１
SD1
SB１
SG1 SG１
COM2
SA２
COM2
RD２
SB２ SD２
SG２ SG２
DI DI
COM COM
Terminal
number
Communications
RS485(COM1)
+
Communications
RS422A(COM2)
+
External digital
input 1 point
Communications
RS485(COM1)
+
Communications
RS485(COM2)
+
External digital
input 1 point
COM1
SA１
COM1
SA１
SB１ SB１
SG１ SG１
COM2
RDA２
COM2
SA２
RDB２ SB２
SDA２ SG２
SDB２
DI DI
COM COM
Note) There is no insulation between communication 2 ports
Terminal
number
External
signal
input 8
points
External
signal
output 8
points
External
signal
output 5
points
+
External
signal
input 3
points
External
signal
output 4
points
+
External
signal
input 4
points
DI
DO DO DO
DI
DO DO DO
DI
DO DO
DO
DI
DO DO
DO
DI
DO DO DI
DI
DO
DI
DI
DI
DO
DI
DI
DI
DO
DI
DI
COM
COM
COM COM
KP1 ④ ⑤ ⑥ C ⑧ ⑨ ⑩ － ⑫ ⑬ ⑭
④ Input signal
0: Universal input
4: 4-wire resistance thermometer
⑤ Control mode (Output 1)
1: ON-OFF pulse type PID
2: ON-OFF servo type PID (Standard specification)
3: Current output type PID
5: SSR drive pulse type PID
6: Voltage output type PID
8: ON-OFF servo type PID (Very little load specifications)
⑥ Control mode (Output 2)*
0: None
1: ON-OFF pulse type PID *1
3: Current output type PID *1
5: SSR drive pulse type PID *1
6: Voltage output type PID *1
⑧ Communications interface (Zone 1)*
0: None
R: RS232C
A: RS422A
S: RS485
T: 5 time signal output
N: 4 status signal outputs + End signal
D: 4 external drive inputs
P: Pattern select input
M: 4 time signal output + End signal
Model code list
