E11
⑨ Transmission signal output (Zone 2)*
0: None
1: 4 to 20mA
2: 0 to 1V
3: 0 to 10V
4: Other
T: 5 time signal outputs
N: 4 status signal outputs + End signal
D: 4 external drive inputs
P: Pattern select input
M: 4 time signal outputs + End signal
⑩ External drive input (Zone 3)*
0: None
5:
4 time signal outputs + end signal + 3 external drive inputs
6: 5 time signal outputs + 3 external drive inputs
7: 4 status signal outputs + 4 external drive inputs
8: 3 external drive inputs + Pattern select input
T: 5 time signal outputs
N: 4 status signal outputs + End signal
D: 4 external drive inputs
P: Pattern select input
M: 4 time signal outputs + End signal
⑫ Case color
G: Gray
B: Black
⑬
IP54 panel sealing specifications and terminal cover*
0: None
1: Terminal cover
2: IP54 panel sealing specifications＋No terminal cover
3: IP54 panel sealing specifications＋Terminal cover
⑭ Power supply voltage
A: 100 to 240V (AC)
D: 24V (AC/DC)
* Option
*1: Control mode (output number 1) can be selected from 1, 3, 5, 6.
Note: Common options of zone 1,2,3 are designated priority form
zone 3 ordering [T], [N], [D], [P], [M]
KP2 ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ - ⑫ ⑬ ⑭
④ Input signal
0: Universal input
4: 4-wire resistance thermometer
⑤ Control mode (Output 1)
1: ON-OFF pulse type PID
2: ON-OFF servo type PID
(Standard specifications)
3: Current output type PID
5: SSR drive pulse type PID
6: Voltage output type PID
8: ON-OFF servo type PID
(Very little load specifications)
⑥ Control mode (Output 2) *
0: None
1: ON-OFF pulse type PID *1
3: Current output type PID *1
5: SSR drive pulse type PID *1
6: Voltage output type PID *1
⑦ Zone 1 *
0: None
9: Heater snapping wire alarm *2
P: External signal input 6 points
M:
External signal input 4 points + Heater snapping wire alarm
*2
T: 5 time signal outputs
N: 4 status signal outputs + End signal
⑧ Zone 2 *
0: None
1: Transmission signal output
(High performance type: 4 to 20mA)
2: Transmission signal output
(High performance type: 0 to 1V)
3: Transmission signal output
(High performance type: 0 to 10V)
4: Transmission signal output
(High performance type: Others)
J: Transmission signal output (General type: 4 to 20mA)
K: Transmission signal output (General type: 0 to 1V)
L: Transmission signal output (General type: 0 to 10V)
9: Heater snapping wire alarm *2
P: External input signal 6 points
M:
External input signal 4 points + Heater snapping wire alarm
*2
T: 5 time signal outputs
N: 4 status signal outputs + End signal
⑨ Additional specifications of zone 2 *
0: None
J: Transmission signal output 2
(General type: 4 to 20mA) *3
K: Transmission signal output, output 2
(General type: 0 to 1V)
*3
L: Transmission signal output, output 2
(General type: 0 to 10V) *3
H: Transmitter power supply *4
Model code list
