CHINT NXZ Series - Split-Type Display Module; Module Dimensions and Mounting

09
NXZ Automatic Transfer Switch
54
109
127
829
6
Split-type Display Module
Outline size
127
111~112
55~56
2Xφ 3.5
Installation cabinet opening size (mm)
Figure 11 Split-type display module
Figure 12 Installation cabinet opening size
