NXZ Automatic Transfer Switch
10
3
2
0.8N·m
ST2.9
4
2 nuts
2 screws
Note: The nuts are installed by fastening screws on the back.
0.9N m·
M3
5 6
7
1
2
2
Split (cabinet surface) installation of display module
Figure 13 Split installation of display module
