CHINT NXZM User Manual

NXZM、NXZ(H)M Automatic Transfer Switch
02
Manual test
Power-on test
Turn the toggle switch to
the Manual position
Off position Normal On position
Alternative
On position
Off position
Reset the handle
Turn the toggle switch to
the Automatic position
Automatic mode Manual mode Setting mode
Failure alarm
(absent for PC class)
Automatic transfer
Operating transfer
delay time
Automatic transfer
Return transfer
delay time
Generator activationStop mode
Fig 2 Manual test
Fig 3 Power-on test
