CHINT NXZM User Manual

1
2
Applicatin Information
a) The normal application temperature of the product is -5℃~+40℃;
Note: If you need to use the product under -25℃~+70℃, please consult the manufacturer.
b) If you need to use the product above 2000m altitude, please consult the manufacturer;
c) Pollution class: class 3;
d) Installation category of main circuit: Ⅲ
e) Enclosure protection class: IP20.
;
Inspection and Test
01
NXZM、NXZ(H)M Automatic Transfer Switch
Inspection
Tools required
Phillips screwdriver
Word screwdriver
Allen wrench
Hex wrench
Fig 1 Inspection
Product
model
Total
(Pcs)
Wiring screw
Flash barrier
M6 X 12 M8 X 16 M8 X 16 M10 X 30 M12 X 35
3P
4P
3P
4P
2X6
2X8
2X4
2X6
NXZM-63、125
HNXZ M-63、125
NXZM-160
HNXZ M-160
NXZM-250
HNXZ M-250
NXZM-400、630
HNXZ M-400、630
NXZM-800
HNXZ M-800
wiring
terminal
of
external
signal
(controller)
Type A
Type AT
Type B
Type BT
split wire
2m (optional)
5
6
7
1
Tabla 1 Standard accessories
1.Determine
product
technical
parameters.
2.Type AT and
BT controllers
have the
function of
communication.
