CHINT NXZM User Manual

NXZM、NXZ(H)M Automatic Transfer Switch
04
Dimensions of split module of controller and cabinet door
105
64
4.5
17
101
60
60≤a≤62
101≤b≤103
Thickness≤2.5
Unit: mm
4
Installation and wiring
Wire connection dimension
Unit: mm
Product model
NXZM/NXZHM-63
NXZM/NXZHM-125
NXZM/NXZHM-160
NXZM/NXZHM-250
NXZM/NXZHM-400
NXZM/NXZHM-630
NXZM/NXZHM-800
a b c Torque
8.0
7.5
10
10.5
15
17.5
16
23.5
30.5
43
6.5
8.5
8.5
11.5
14
4 N·m
10 N·m
12 N·m
30 N·m
40 N·m
Fig 5 Dimensions of split module of controller and cabinet door
Fig 6 Wire connection dimension
Tabla 3 Wire connection dimension
