Étude supports a single stereo
output. In order to connect Étude
to loudspeakers, use high-quality
loudspeaker cable terminated
with 4mm banana plugs or 6mm
spades. Bare wire can be used,
but it is not recommended.
4.1 Placement
4.2 Connecting Étude to
ancillary equipment
4.3 Line level inputs
4.4 Audio outputs
4.5 Power-on sequence
4.6 Earthing issues in Europe
Audio outputs 4.4
20 // 26
Connect the black (negative)
terminal from Étude to the
negative terminal on your
loudspeaker and the red
(positive) terminal from Étude to
the red positive terminal on your
loudspeaker. Repeat for each
channel.
Left channel positive
speaker terminal
Left channel negative
speaker terminal
Right channel negative
speaker terminal
Right channel positive
speaker terminal
