Figure 3-115. Tank Level Indicators
3-59 3-59
Optional Holding Tank
The RJ and RK models offer an optional holding tank with a Techma head and/or the gray water option.
The tank is located below the cockpit floor.
Figure 3-114. Optional Holding Tank
1
4
Figure 3-117. Macerator Pump & Shut-Off Valve
3
WATER TANK
Figure 3-116. Discharge Sea Cock
Table 3.6. Holding Tank Assembly
1 Holding Tank Inlet From Head
Item Description
3 Fresh Water Tank
2 Waste Tank Level Indicators
5 Discharge Seacock
4 Waste Tank
7 Shut-off Valve To Macerator
6 Macerator Pump
Hose to dockside pump-out located at the transom
Hose to macerator pump
2
Hose to macerator pump located in the engine room
WASTE TANK
6
7
5
6
7
