Chris King R45 - R45 Rear Hub Exploded Diagram; Campagnolo Hub Type

axle end
adjusting cone
front hubshell bearing
front hubshell bearing inner seal
A.
B.
C.
D.
front hubshell
front axle O-ring
front main axle
E.
F.
G.
R45 rear hub exploded diagram
B C
D E F G H I
QR insert
O-ring
adjusting clamp screw
adjusting clamp
small rear hubshell bearing
small hubshell bearing inner seal
rear hubshell
spring retainer w/ O-ring
drive spring
drive ring
driven ring
large hubshell bearing inner seal
large hubshell bearing
O-Ring
Shimano®/SRAM® driveshell
inboard driveshell bearing inner seal
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
M.
N.
O.
P.
inboard driveshell bearing
Shimano®/SRAM® bearing spacer spring (silver)
bearing spacer spring O-ring
outboard driveshell bearing
Shimano®/SRAM® rear axle
bearing spacer spring O-ring
Campagnolo® driveshell
inboard driveshell bearing inner seal
inboard driveshell bearing
Campagnolo® bearing spacer spring (black)
bearing spacer spring O-ring
Campagnolo® rear axle
outboard driveshell bearing
retainer sleeve
Campagnolo® 11t lockring
Q.
R.
S.
T.
U.
V.
W.
X.
Y.
Z.
AA.
AB.
AC.
AD.
AE.
A
J K
L
M
N O P Q R S T U
V W X Y
Shimano®/SRAM® Hub Type
Z AA AB AC AD
AE
Campagnolo® Hub Type
