CC2 Electric Barbecue Cooktop (Part numbers 1005 and 1006)
18 | Installation
495 mm
495 mm
FIG. 9
STEP 4
Using two people, lift the appliance out of the container and turn over, so that the
cooking surface faces upwards. Position over the cut out in the bench. Drop the power
cable into the cut-out hole then lower the appliance. Ensure the 8mm threaded bolts
align with the slotted holes in the anti-rotation brackets. Install the washers and wing
nuts, but do not tighten completely.
2.2 Installation
