CC2 Electric Barbecue Cooktop (Part numbers 1005 and 1006)
8
Rated voltage 230-240V AC
Frequency 50Hz
Rate current 15A
Element 3.5KW
Nominal target temp 255 degrees
Nominal cook time 20 min
Nominal tare weight 20kg
Nominal packed weight 25kg
Requires RCD 30mA
Requires 20A circuit breaker
IP Rating IPX4
Plan View Above
Bench
Below
Bench
Hotplate/
Grillplate
Cooking
Surface
Dimensions
in mm
600 x 600 56 160 536 x 536 435 x 435
1.7 Specifications
| General information
TABLE 1
This appliance has been tested and certified to Australian Standards (RCM) and European
standards (CE) declaration of conformity certificate available on request. The Product
Identification Label contains the following information:
• Type and model
• Electrical ratings
• RCM and CE compliance marks
• Manufacturers name and contact details
• Serial number
DO NOT REMOVE THIS PRODUCT IDENTIFICATION LABEL. IF IT IS ILLEGIBLE OR
DAMAGED, CONTACT CHRISTIE.
Product safety features include a six-second time delay start button located on the cooktop,
and an over temperature normally closed thermostat (twin pole), with a manual reset button that
will independently shut off power to the relay in case of overheating.
1.6 Declaration of conformity
