Chroma 66204 - Page 92

Digital Power Meter 66203/66204 User’s Manual
5-16
STATus:CHANnel:NTRansition
Type: Channel-Specific.
Description: Programmable filters that determine 1-to-0 transition in the
Condition register will set the corresponding bit of the Event register.
Setting syntax: STATus:CHANnel:NTRansition<space><NR1><PMT>
Setting parameters: <NR1>, 0 ~ 65535, Unit = None
Setting example: STAT:CHAN:NTR 4 Set over current bit 2 from 1-to-0.
Query syntax: STATus:CHANnel:NTRansition?[<space><MAX | MIN>]<PMT>
Return parameters: <NR1>
Query example: STAT:CHAN:NTR?
Return example: 4
STATus:CSUMmary:ENABle
Type: Channel-Independent.
Description: Mask to select which bit in the Channel Event register is allowed to
be summed into the CSUM (Channel Summary) bit
for the Status
Byte register.
Setting syntax: STATus:CSUMmary:ENABle<space><NR1><PMT>
Setting parameters: <NR1>, 0 ~ 65535, Unit = None
Bit Configuration of Channel Summary Register
Bit Position 15~4 3 2 1 0
Channel - 4 3 2 1
Bit Weight - 8 4 2 1
Setting example: STAT:CSUM:ENAB 3
Query syntax: STATus:CSUMmary:ENABle?[<space><MAX | MIN>]<PMT>
Return parameters: <NR1>
Query example: STAT:CSUM:ENAB?
Return example: 3
STATus:CSUMmary:EVENt?
Type: Channel-Independent.
Description: Indicate all channels of which an enabled STAT:CHAN Event
has occurred since last time the register was read.
Query syntax: STATus:CSUMmary:EVENt?<PMT>
Return parameters: <NR1>
Query example: STAT:CSUM:EVEN?
Return example: 3
CHANNEL Sub-system
CHANnel
Type: System.
Description: Selects a channel of which the coming channel-specific command
will be received and executed.
Setting syntax: CHANnel<space><NR1><PMT>
Setting parameters: <NR1>, 1 ~ 4: Channel 1 ~ Channel 4
Query syntax: CHANnel?[<space><MAX | MIN>]<PMT>
Return parameters: <NR1>, 1 ~ 4
