Chroma 66204 - FETCH & MEASURE Sub-system

Using Remote Control
5-17
Header on: :CHANNEL<space><NR1><RMT>
Header off: <NR1><RMT>
Example: none
CHANnel :ID?
Type: System.
Description: This query requests the module to identify itself.
Setting syntax: none
Setting parameters: none
Query syntax: CHANnel:ID?<PMT>
Return parameters: <SRD>, “Manufacturer,Model name,Serial number,F/W version,
FPGA version,PCB version”
Information Example
Manufacturer Chroma ATE
Model name 66204
Serial number 66204M000066
F/W version 1.00
FPGA version 1.00
PCB version 1.00
Header on: :CHANNEL:ID<space><SRD><RMT>
Header off: <SRD><RMT>
Example: none
FETCH & MEASURE Sub-system
FETCh? {<CRD1>{,<CRD2>{, … {,<CRD10>}}}}}}
MEASure? {<CRD1>{,<CRD2>{, … {,<CRD10>}}}}}}
Type: Channel-Specific.
Description: This command lets the user get measurement data from the Power
Meter. Two measurement commands are available: MEASure and
FETCh. MEASure triggers the acquisition of new data before
returning data. FETCh returns the previously acquired data from
measurement buffer. The return could be -1, -2, -3 and <NR2>.
-1: The first time integrated calculation is not complete yet.
-2: RCE represents “range change error” when integration process
is executing.
-3: Invalid data when OVR、OCR、OCP occur.
Setting syntax: none
Setting parameters: none
Query syntax:
FETCh?<PMT>
FETCh?<space><CRD>,<CRD>,…up to 10<PMT>
MEASure?<PMT>
MEASure?<space><CRD>,<CRD>,…up to 10<PMT>
Query parameters: <CRD>, V, VPK+, VPK-, THDV, I, IPK+, IPK-, IS, CFI, THDI, W, PF,
VA, VAR, ENEG, FREQ, VDC, IDC, WDC
Return parameters: <NR2>
Example 1:
Query: FETC?<PMT>
Response:
