Digital Power Meter 66203/66204 User’s Manual
5-18
Header on:
:FETCH<space>V<space><NR2>;VPK+<space><NR2>;VPK-<space><
NR2>;THDV<space><NR2>;I<space><NR2>;IPK+<space><NR2>;IPK-<
space><NR2>;IS<space><NR2>;CFI<space><NR2>;THDI<space><NR
2>;W<space><NR2>;PF<space><NR2>;VA<space><NR2>;VAR<space
><NR2>;ENEG<space><NR2>;FREQ<space><NR2>;VDC<space><NR
2>;IDC<space><NR2>;WDC<space><NR2><RMT>
Header off:
<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<N
R2>;NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>
<RMT>
Separator 0:
<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<N
R2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2>,<NR2
><RMT>
Separator 1:
<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<N
R2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2>;<NR2
><RMT>
Example 2:
Query: FETC?<space>V,I,W<PMT>
Response:
Header on:
:FETCH<space>V<space><NR2>,I<space><NR2>,W<space><NR2><R
MT>
Header off:
<NR2>,<NR2>,<NR2><RMT>
Separator 0:
<NR2>,<NR2>,<NR2><RMT>
Separator 1:
<NR2>;<NR2>;<NR2><RMT>
FETCh[:SCALar]:VOLTage:RMS? {<NR1>}
MEASure[:SCALar]:VOLTage:RMS? {<NR1>}
Type: Channel-Specific.
Description: These queries return the r.m.s. voltage. The return could be -1, -2,
-3 and <NR2>.
-1: The first time integrated calculation is not complete yet.
-2: RCE represents “range change error” when integration process
is executing.
-3: Invalid data when OVR occur.
Setting syntax: none
Setting parameters: none
Query syntax: FETCh:VOLTage:RMS?<PMT>,
FETCh:VOLTage:RMS?<space><NR1><PMT>,
MEASure:VOLTage:RMS?<PMT>,
MEASure:VOLTage:RMS?<space><NR1><PMT>
Query parameters: <NR1>, 0 ~ 4, 0:All channel, 1~4:Channel 1 ~ Channel 4
Return parameters: <NR2>
Header on: :FETCH:VOLTAGE:RMS<space><NR2><RMT>
