Chromalox 1604 User Manual

11
SEr3 = Baud rate for serial link
Not available when SEr1 = OFF
From 600 to 19200 baud.
NOTE: 19200 baud is shown on display as 19.20.
SEr4 = Byte format for serial link
Not available when SEr1 = OFF
7E = 7 bits + even parity (For ERO protocol only)
7O = 7 bits + odd parity (For ERO protocol only)
8E = 8 bits + even parity
8O = 8 bits + odd parity
8 = 8 bits no parity
P1 - Input type and standard range
0 = TC type L range 0 / +400.0°C
1 = TC type L range 0 / +900 °C
2 = TC type J range -100.0 / +400.0 °C
3 = TC type J range -100 / +1000 °C
4 = TC type K range -100.0 / +400.0 °C
5 = TC type K range -100 / +1370 °C
6 = TC type N range -100 / +1400 °C
7 = TC type R range 0 / +1760 °C
8 = TC type S range 0 / +1760 °C
9 = RTD type Pt 100 range -199.9 / +400.0 °C
10 = RTD type Pt 100 range -200 / +800 °C
11 = mV Linear range 0 / 60 mV
12 = mV Linear range 12 / 60 mV
13 = mA Linear range 0 / 20 mA
14 = mA Linear range 4 / 20 mA
15 = V Linear range 0 / 5 V
16 = V Linear range 1 / 5 V
17 = V Linear range 0 / 10 V
18 = V Linear range 2 / 10 V
19 = TC type L range 0 / +1650 °F
20 = TC type J range -150 / +1830 °F
21 = TC type K range -150 / +2500 °F
22 = TC type N range -150 / +2550 °F
23 = TC type R range 0 / +3200 °F
24 = TC type S range 0 / +3200 °F
25 = RTD type Pt 100 range -199.9 / +400.0 °F
26 = RTD type Pt 100 range -330 / +1470 °F
27 = TC type T range -199.9 / +400.0 °C
28 = TC type T range -330 / +750 °F
NOTE: selecting P1 = 0, 2, 4, 9, 25 or 27, the
instrument set automatically P36 = FLtr. For all
the remaining ranges it will set P36 = nOFL.
If a different selection is desired, P36 may be
modified.
P2 = Decimal point position
This parameter is available only when a linear input
is selected (P1 = 11, 12, 13, 14, 15, 16, 17 or 18).
----. = No decimal figure.
---.- = One decimal figure.
--.-- = Two decimal figures.
-.--- = Three decimal figures.
P3 = Initial scale value
For linear inputs it is programmable from -1999 to
4000.
For TC and RTD input it is programmable within
the input range.
When this parameter is modified, rL parameter
will be re-aligned to it.
P4 = Full scale value
For linear inputs it is programmable from -1999 to
4000.
For TC and RTD input it is programmable within
the input range.
When this parameter is modified, rH parameter
will be re-aligned to it.
1604-1-BC.p65 5/16/00, 10:25 AM11
