CONTROL ACTIONS
Control action: PID + SMART
Type: One (heating or cooling) or two (heating
and cooling) control outputs.
Proportional Band (Pb):
Range: - from 1.0 to 100.0 % of the input span
for process with one control output.
- from 1.5 to 100.0 % of the input span
for process with two control output.
When Pb=0, the control action becomes ON/OFF.
Hysteresis (for ON/OFF control action):
from 0.1% to 10.0% of the input span.
Integral time (Ti): from 1s to 20 min. or
excluded.
Derivative time (Td): from 0 s to 10 min.
If zero value is selected, the derivative action is
excluded.
Integral pre-load:
- from 0.0 to 100.0 % for one control output
- from -100.0 (cooling) to +100.0 % (heating) for
two control output.
SMART: keyboard enabling/disabling
Auto/Manual: selectable by front pushbutton.
Auto/Manual transfer: bumpless method type
Indicator "MAN" : OFF in auto mode and lit in
manual mode.
OUTPUTS
Control output updating time :
- 250 ms when a linear input is selected
- 500 ms when a TC or RTD input is selected.
Action: direct/reverse programmable by front
keyboard.
Output level indication:
The instrument displays separately the output 1
level (heating) and the output 2 level (cooling).
E) CURRENT TRANSFORMER INPUT FOR
OUT1 FAILURE DETECTION
The instruments equipped with this feature are
capable, by means of a CT, to detect and signal a
possible failure of the line driven by out 1 (see
"OUT 1 failure detection").
Input range: 50 mA AC.
Scaling: programmable from 10 A to 100 A (with
1 A step).
Resolution:
- for full scale up to 20 A: 0.1 A.
- for full scale from 21 A to 100 A: 1 A
Minimum duration of the period (ON or OFF)
to perform the measurement: 400 ms.
NOTE : this function excludes the logic input
(external set point selection).
SET POINTS
This instrument allows to use 2 set points: SP and
SP2.
The set point selection is possible only by logic
input.
Set point transfer:
The transfer between one set point to another (or
between two different set point values) may be
realized by a step transfer or by a ramp with two
different programmable rate of change (ramp up
and ramp down).
Slope value: 1 - 100 eng. unit/min or step.
Set points limiter: RLO and RHI parameters, pro-
grammable.
