95Chromalox 2104 Technical Manual
Ramp/Soak Page
MENU Description Available Settings Factory Settings Security
UNITUNIT
UNITUNIT
UNIT Time Units SEC = seconds (1 to 9999) SEc C
MIN = minutes (0.1 to 999.9)
HR = hours (0.01 to 99.99)
STBYSTBY
STBYSTBY
STBY Standby Instrument Sensor Span Span Low
Setpoint
INT1INT1
INT1INT1
INT1 Interval 1 Time see Time Units Menu (above) 0
SP1SP1
SP1SP1
SP1 Setpoint 1 Instrument Sensor Span Span Low
•
•Intervals 2-15
•Time and Setpoint
IN16IN16
IN16IN16
IN16 Interval 16 Time see Time Units Menu (above) 0
SP16SP16
SP16SP16
SP16 Setpoint 16 Instrument Sensor Span Span Low
CC
CC
C
ONTONT
ONTONT
ONT Continuous OFF OFF
Program ON
FROFRO
FROFRO
FRO Loop from the 1 TO 16 1
end of interval
TOTO
TOTO
TO To the beginning 1 TO 16 1
of interval
NONO
NONO
NO Number of times 0 TO 9999 0
SBETSBET
SBETSBET
SBET Standby OFF = All off OFF
Events E3 = Event Output 3 On
E4 = Event Output 4 On
E43 = Event Outputs 4 & 3 On
E5 = Event Output 5 On
E53 = Event Outputs 5 & 3 On
E54 = Event Outputs 5 & 4 On
E543 = Event Outputs 5, 4, 3 On
ILEILE
ILEILE
ILE Interval 1 OFF = All off OFF
Events E3 = Event Output 3 On
E4 = Event Output 4 On
E43 = Event Outputs 4 & 3 On
E5 = Event Output 5 On
E53 = Event Outputs 5 & 3 On
E54 = Event Outputs 5 & 4 On
E543 = Event Outputs 5, 4, 3 On
IL6EIL6E
IL6EIL6E
IL6E Interval 16 same as above OFF
Events
GG
GG
G
SDBSDB
SDBSDB
SDB Guaranteed OFF, 1°F to sensor range 0°F
Soak differential
Ramp/Soak Page
See pages 41-45 for details.
