Output #3 Page (continued)
MENU Description Available Settings Factory Settings Security
AA
AA
A
OL3OL3
OL3OL3
OL3 Alarm #3 Instrument Sensor Span Span Low C
Low Setpoint
AA
AA
A
HI3HI3
HI3HI3
HI3 Alarm #3 Instrument Sensor Span Span High
High Setpoint
DB3DB3
DB3DB3
DB3 Output #3 0 to 100°F 1°F
Dead Band
(Alarm Hysteresis)
INH3INH3
INH3INH3
INH3 Alarm #3 OFF OFF
Inhibit ON
Output #4 Page
MENU Description Available Settings Factory Settings Security
TYP4TYP4
TYP4TYP4
TYP4 Output #4 Type OFF = Disabled OFF C
ALR = Alarm Output
ENT = Event Output
(Setup Event Output parameters
on Ramp/Soak Page)
AA
AA
A
LR4LR4
LR4LR4
LR4 Alarm #4 Type NONE = Disabled (off) NONE
HI = High Alarm
LO = Low Alarm
HILO = High-Low Alarm
PDE = Plus Deviation Alarm
-DE = Minus Deviation Alarm
DE = Plus/Minus Deviation Alarm
LOOP = Control Loop Protection Alarm
Output # 3 Page
See page 50 for details.
Output # 4 Page
See page 51 for details.
