100 Chromalox 2104 Technical Manual
Output #4 Page (continued)
MENU Description Available Settings Factory Settings Security
RR
RR
R
LL
LL
L
Y4Y4
Y4Y4
Y4 Alarm #4 NDE = Normally de-energized NDE C
Relay Action non-latching
NE = Normally energized
non-latching
NDEL = Normally de-energized
latching
NEL = Normally energized
latching
AA
AA
A
OL4OL4
OL4OL4
OL4 Alarm #4 Instrument Sensor Span Span Low
Low Setpoint
AA
AA
A
HI4HI4
HI4HI4
HI4 Alarm #4 Instrument Sensor Span Span High
High Setpoint
DB4DB4
DB4DB4
DB4 Output #4 0 to 100°F 1°F
Dead Band
(Alarm Hysteresis)
INH4INH4
INH4INH4
INH4 Alarm #4 OFF OFF
Inhibit ON
Output # 4 Page
See page 51 for details.
Output #5 Page
MENU Description Available Settings Factory Settings Security
TYP5TYP5
TYP5TYP5
TYP5 Output #5 Type OFF = Disabled OFF C
ALR = Alarm Output
ENT = Event Output
(Setup Event Output parameters
on Ramp/Soak Page)
AA
AA
A
LR5LR5
LR5LR5
LR5 Alarm #5 Type NONE = Disabled (off) NONE
HI = High Alarm
LO = Low Alarm
HILO = High-Low Alarm
PDE = Plus Deviation Alarm
-DE = Minus Deviation Alarm
DE = Plus/Minus Deviation Alarm
LOOP = Control Loop Protection Alarm
Output # 5 Page
See page 52 for details.
