Coolant Temp
Displays the actual coolant temperature.
•
AWD Status — If Equipped
Displays a vehicle ICON with four wheels highlighted
and ⬙AWD⬙ if All Wheel Drive is active. Displays a
vehicle ICON with two wheels highlighted and ⬙RWD⬙ if
All Wheel Drive is inactive.
•
Oil Temperature
Displays the actual oil temperature.
•
Oil Pressure
Displays the actual oil pressure.
•
Trans Temperature
Displays the actual transmission temperature.
•
Engine Hours
Displays the number of hours of engine operation.
Messages #
Select from Main Menu using the UP or DOWN buttons.
This feature shows the number of stored warning mes-
sages (in the # place holder). Pressing the SELECT button
will allow you to see what the stored messages are.
Pressing the BACK button takes you back to the Main
Menu.
Turn Menu OFF
Select from Main Menu using the DOWN button. Press-
ing the SELECT button blanks the menu display. Pressing
any one of the four steering wheel buttons brings the
menu back.
Uconnect Touch™ SETTINGS
The Uconnect Touch™ system uses a combination of soft
and hard keys located on the center of the instrument
panel that allows you to access and change the customer
programmable features.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 303
