Chrysler 300 2012 - Page 511

Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
33 — 15 Amp
Blue
Ignition Switch/Wireless
Module
34 — 10 Amp
Red
Steering Column
Module/Clock
35 — 10 Amp
Red
Battery Sensor
36 — — Fuse — Spare
37 — 15 Amp
Blue
Radio
38 — 20 Amp
Yellow
Power Outlet Inside
Arm Rest
40 — — Fuse — Spare
41 — — Fuse — Spare
42 30 Amp
Pink
— Rear Defrost
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
43 — 25 Amp
Natural
Rear Heated Seats/
Steering Wheel
44 — 10 Amp
Red
Park Assist/Blind Spot/
Camera
45 — 15 Amp
Blue
Cluster/Rearview
Mirror/Compass
46 — 10 Amp
Red
Adaptive Cruise Control
47 — 10 Amp
Red
Adaptive Front Lighting
48 — 20 Amp
Yellow
Active Suspension
49 — — Fuse — Spare
50 — — Fuse — Spare
7
MAINTAINING YOUR VEHICLE 509
