8 GETTING TO KNOW YOUR VEHICLE
(Continued)
AC LEVEL 1 CHARGING (120 VOLT,
15 A
MP)
Your vehicle is equipped with a 120 Volt AC, SAE
J1772 Level 1 Electric Vehicle Supply
Equipment (EVSE), also referred to as a
charging cordset. AC Level 1 charging requires
a conventional NEMA 5-15R 120 Volt AC
grounded wall receptacle along with the
portable charging cordset provided with the
vehicle.
Portable Charging Cordset (EVSE)
To access the portable charging cordset, open
the door of the cargo area storage bin, on the
driver’s side, and remove the charging cordset
from the storage bag.
NOTE:
After use, the EVSE should be placed in the
storage bag and put back in the cargo area
storage bin. If the charging cordset will be left
outside the vehicle, be sure to protect the
charging cordset’s vehicle connection end from
moisture, dirt, and debris accumulation and
contamination.
Cargo Area Storage Bin
NOTE:
The portable charging cordset is used for AC
Level 1 charging only.
WARNING!
INSTRUCTIONS PERTAINING TO A RISK OF
FIRE OR ELECTRIC SHOCK: Shock, fire,
property damage, or personal injury may
occur if the Portable EVSE Cordset is not used
properly. There are no serviceable parts
contained in the Portable EVSE Cordset. Any
attempt to service it may result in shock, fire,
property damage, or personal injury.
WARNING!
IMPORTANT SAFETY INSTRUCTIONS
PERTAINING TO A RISK OF FIRE OR ELECTRIC
SHOCK: This manual contains important
instructions that should be followed during
installation, operation, and maintenance of
the unit. When using electric products, basic
precautions should always be followed,
including the following:
Read all instructions before using this
product.
