88 SERVICING AND MAINTENANCE
* 30A mini fuse is substituted for 25A Circuit Breaker.
STORING THE VEHICLE
If the vehicle should remain stationary for more
than a month, observe the following
precautions:
Park your vehicle in a covered, dry and
possibly airy location with the windows open
slightly.
Check that the Electric Park Brake is not
engaged.
Disconnect the negative (-) terminal from the
battery post and be sure that the battery is
fully charged. During storage check battery
charge quarterly.
NOTE:
Disconnecting the 12 Volt battery will prevent
the High Voltage (HV) Battery from accepting a
charge from the Electric Vehicle Supply Equip-
ment (EVSE). Also, the vehicle will not condition
the HV Battery (if needed and connected to a
powered EVSE). If the HV Battery is not able to
condition itself and it becomes cold enough (or
hot enough), the vehicle will not start until the
HV Battery’s cell temperatures are between
-22°F (-30°C) and 122°F (50°C).
If you do not disconnect the battery from the
electrical system, check the battery charge
every 30 days.
Whenever you leave the vehicle stationary for
two weeks or more, idle the vehicle for
approximately five minutes, with the air
conditioning system on and high fan speed.
This will ensure proper lubrication of the
system, thus minimizing the possibility of
damage to the compressor when the vehicle
is put back into operation.
Plug in the vehicle when not using it when-
ever possible.
F100A –
10 Amp Red
QVPM
F100B – Rr Camera / LBSS / RBSS / CVPM / Humidity Snsr / In Car Temp Snsr
Circuit Breakers
CB1 25 Amp Power Seat (Driver)
CB2 25 Amp Power Seat (Pass)*
CB3 – Not Used
Cavity Cartridge Fuse Blade Fuse Description
