SERVICING AND MAINTENANCE 87
F82 – – Not Used
F83 30 Amp Pink – Trans Oil Pump
F84 – – Not Used
F85 – 20 Amp Yellow Cigar Lighter
F86 – – Not Used
F87 – – Not Used
F88 – 20 Amp Yellow Front Heated Seats
F89 – 20 Amp Yellow Rear Heated Seats
F90 – 5 Amp Tan EBCM - ECU
F91 – 15 Amp Blue Front Ventilated Seats/Heated Steering Wheel
F92A – 5 Amp Tan Security Gateway
F92B – – Not Used
F93 – – Not Used
F94 40 Amp Green – ESC - Motor Pump
F95A –
10 Amp Red
USB Charge Only Port
F95B – Selectable Fuse Location
F96 – 10 Amp Red Occupant Restraint Controller (ORC) (Airbag)
F97 – 10 Amp Red Occupant Restraint Controller (ORC) (Airbag)
F98 – – Not Used
F99 – – Not Used
Cavity Cartridge Fuse Blade Fuse Description
7
21_RU2_H_SU_EN_USC_t.book Page 87
