86 SERVICING AND MAINTENANCE
F67 – 10 Amp Red HALF / PTS / Drivers Assist System Module (DASM)
F68 – – Not Used
F69A –
15 Amp Blue
BPCM
F69B – BPCM (Redundant)
F70 – 5 Amp Tan EAC
F71 – 20 Amp Yellow Horn
F72 – – Not Used
F73 30 Amp Pink – Rear Defroster (EBL)
F74 – – Not Used
F75 – 5 Amp Tan Overhead Console / Rear ICS
F76 – 20 Amp Yellow Uconnect / DCSD / Telematics
F77A –
10 Amp Red
Rear Entertainment / Media HUB / 3RD & 2ND Row USB CHRG / Vacuum
Cleaner SW Backlight / 3RD Row Recliner SW Backlight / 2ND Row Stow N Go
SW Backlight / LT&RT Sliding Door Backlight
F77B – B. Sunroof / Rain sensor / Rear View Mirror / PIM
F78A –
15 Amp Blue
Transmission Control Module (TCM) / Electric Power Steering 2 / E-Shifter / ESM
F78B – Instrument Cluster
F79A –
10 Amp Red
ICS / Frt & Rr HVAC / EPB Sw / SCCM
F79B – Not Used
F80 – 5 Amp Tan OBCM
F81 – 5 Amp Tan APM
Cavity Cartridge Fuse Blade Fuse Description
