SERVICING AND MAINTENANCE 85
F49 25 Amp Clear – Rear Sliding Door Module - Lt
F50 25 Amp Clear – Rear Door Control Module - Rt
F51 30 Amp Pink – Front Wiper
F52 – – Not Used
F53 – – Not Used
F54 40 Amp Green – ESP-ECU And Valves
F55A –
15 Amp Blue
RF Hub/KIN/ESL - BUX Only
F55B – DVD / VRM
F56A –
10 Amp Red
FRT. & RR HVAC CTRL/ OCM / ESL
F56B – B. EPS / ESC - Electric Stability Ctr
F57 – 20 Amp Yellow PIM - Main Power Supply
F58 – – Not Used
F59 – – Not Used
F60 – 20 Amp Yellow Rear Cargo APO
F61 – – Not Used
F62 – 20 Amp Yellow PIM-Main PWR Supply
F63 – – Not Used
F64 – – Not Used
F65 – – Not Used
F66 – 15 Amp Blue Instrument Panel Cluster (IPC) / SGW
Cavity Cartridge Fuse Blade Fuse Description
