84 SERVICING AND MAINTENANCE
F30A –
10 Amp Red
ECM / PIM
F30B – Not Used
F31 – 10 Amp Red 3, 4 way Valves
F32 20 Amp Blue – ECM
F33 30 Amp Pink – Power Liftgate Module
F34 25 Amp Clear – Rear Door Control Module - Lt
F35 25 Amp Clear – Sunroof Control Module
F36 – – Not Used
F37 40 Amp Green – CBC Feed #4 (Exterior Lighting / PCM #2)
F38 – – Not Used
F39 25 Amp Clear – Rear HVAC Blower Motor
F40 20 Amp Blue – Trans Oil Pump
F41 – – Not Used
F42 – – Not Used
F43 – 20 Amp Yellow Fuel Pump Motor
F44 30 Amp Pink – CBC Feed #1 (Interior Lights)
F45 30 Amp Pink – Power Inverter
F46 30 Amp Pink – Driver Door Module
F47 30 Amp Pink – Passenger Door Module
F48 40 Amp Green – EBCM Motor
Cavity Cartridge Fuse Blade Fuse Description
