SERVICING AND MAINTENANCE 83
F13 – – Not Used
F14A –
10 Amp Red
Media Hub 1, 2, 3
F14B – Pwr Lumbar Switch
F15 40 Amp Green – CBC / Power Locks
F16 – 20 Amp Yellow ECM
F17 – – Not Used
F18 40 Amp Green – CBC Feed #4 (Exterior Lights #1)
F19 – – Not Used
F20 – 10 Amp Red Low Temp Passive Pump
F21 20 Amp Blue – PIM - Park PAWL Motor
F22 – – Not Used
F23 – – Not used
F24 – 20 Amp Yellow RR Wiper
F25A –
10 Amp Red
Handsfree (Lt & Rt Rear Door Release Module)
F25B – Active Grill Shutter
F26 40 Amp Green – Front HVAC Blower Motor
F27 25 Amp Clear – RR Slide Door Module - RT
F28A –
10 Amp Red
Diagnostic Port
F28B – USB + AUX (UCI) Port (IP) / Video USB Port
F29 – – Not Used
Cavity Cartridge Fuse Blade Fuse Description
7
