Guidelines for preventing fire and electric
shock:
Ensure the charging cable is positioned so it
will not be stepped on, tripped over, or other-
wise subjected to damage or stress.
There are no user serviceable parts inside.
Do not use the charging cordset if it is visibly
damaged. Contact an authorized dealer for
service.
Do not place fingers, or any other objects
inside the charge connector.
Do not allow children to operate this device.
Adult supervision is mandatory when children
are in proximity when the charging cordset is
in use.
Do not use the charging cable with an exten-
sion cord.
1, 1, 2, 1 Fault & AC Power
EVSE Enclosure
Internal
Temperature is Too
High
Use caution as the Portable EVSE Cordset housing may be hot. It is
recommended to move the Portable EVSE Cordset out of direct sun exposure.
Allow the unit to cool. If error persists, check the Portable EVSE Cordset at a
service location.
1, 1, 1, 2 Fault & AC Power
Hot AC Power Plug
Warning
Use caution as the Portable EVSE Cordset AC Power Plug may be hot. It is
recommended to carefully unplug the unit from the wall outlet and allow it to cool
down. Attempt to charge the vehicle at a different wall outlet. Contact a certified
electrician to inspect/replace the wall outlet that was associated with the Hot AC
Plug event. Charging will still occur, but at a reduced rate.
1, 1, 1, 1 Fault & AC Power
AC Power Plug Over
Temperature
Use caution as the Portable EVSE Cordset AC Power Plug may be hot. It is
recommended to carefully unplug the unit from the wall outlet and allow it to cool
down. Attempt to charge the vehicle at a different outlet. Contact a certified
electrician to inspect/replace the outlet that was associated with the Hot AC Plug
event.
Portable EVSE Cordset Fault Code List
Flashing Fault
Code
Flashing Indicator Fault Indication Recommended Actions
2
