GETTING TO KNOW YOUR INSTRUMENT PANEL 45
All active telltales will display first if applicable.
The system check menu may appear different
based upon equipment options and current
vehicle status. Some telltales are optional and
may not appear.
RED WARNING LIGHTS
Hybrid Electric Vehicle System Service
Light
This warning light will illuminate when
service to the hybrid electric system is
needed. It will be accompanied by a
"Service Hybrid Electric Vehicle
System" message in the cluster. If the telltale
stays on or continues to come on, contact an
authorized dealer as soon as possible.
Plug Status Fault Warning Light
This warning light will illuminate when
a plug status fault is detected (when
vehicle not in motion). It will be
accompanied by a cluster message
indicating the type of fault. You may receive one
of the following messages if a fault is detected:
“Service Charging System” – If you see this
message, it is recommended to unplug and
plug in again, or try a different charging
station. If an issue continues, contact an
authorized dealer to service your high voltage
charging system.
“Issue Detected Check External Charging
Station” – If you see this message, the
charging station maybe powered off, having
internal fault or being scheduled to charge
later. It is recommended to try a different
charging station. If an issue continues, then
contact an authorized dealer.
NOTE:
Older or non-compliant J1772 EVSE models
may not support charging of this vehicle. If
this vehicle does not charge, it may be
connected to a non-compliant Level 2 EVSE,
and will flash indicators. Please identify this
failure to the site operator and/or EVSE
provider.
Before this vehicle can be driven, the EVSE
Charging Cord must be disconnected from
the vehicle.
Torque Limited Warning Light
This warning light illuminates when
vehicle acceleration is limited due to
a reduction in engine or electric motor
performance. Contact an authorized
dealer for service if illumination persists.
GREEN INDICATOR LIGHTS
Ready To Drive Indicator Light
This indicator light will illuminate to
indicate that the vehicle has enough
power to be driven, regardless of the
speed of the vehicle.
Plug Status Indicator Light
When plugged in, the green plug
indicator light will illuminate if the
EVSE charging plug is securely
attached to the charging port. This
indicates that the plug is detected, but doesn't
mean it is charging. It will be accompanied with
a cluster message indicating the charge status:
“Plugged In And Charging”
“Plugged In And Waiting to Charge On A Set
Schedule”
“Plugged in and Charging Complete”
NOTE:
The vehicle cannot be driven until it is
unplugged.
3
