10 MONITOR AFx™ v3.3 LCD Keypad User's Guide
500-9030v3.3
If You Are Being Forced to Enter
A duress (panic) alarm is triggered when you
enter your PIN with the last two digits
reversed. (This can be done at reader
keypads, system LCD keypads, and
condominium LED keypads.)
Normal PIN Example
: 1 2
3 4
If being forced to Enter
: 1 2
4 3
This feature will be available unless it was disabled
by your service technician when the system was
initially set up.
Logging Into the Keypad
(User ID and/or PIN)
"Logging In" provides you with access to the
features of the LCD keypad. To log in:
Open the keypad
cover, and key in
your user ID number
and/or PIN number
as indicated on the
display
When finished viewing or entering items, you can
use the
key to exit (press multiple times as
needed--until the "login" screen appears).
Tip:
You
will also be logged out automatically if you do not
press any keys for approximately one (1) minute.
Overview of Screens (Topics)
When logged in, you will see only the topics
that you have the authority to use. Some or all
of the following topics will be available:
Selecting a Topic:
Press the "
"
key until your
desired topic appears on-screen. Then press the
key directly under your topic to select it.
Off // Stay // On:
The first screen that
you'll see allows you
to arm or disarm the area(s) as desired, or to
access other topics.
Only two of arm/disarm selections will appear
at a time—depending on the present arming-
state of the area(s).
Status / View Status:
This allows checking
the status of various items in the system, or
commanding items into different states.
Additional status screens (Comms, Modem, and
Licns) are accessible by a service technician (i.e.,
service login). These pertain to service issues which
are not pertinent to this guide.
Bypass:
This allows bypassing faulty
sensor(s) so the system ignores them, and/or
to allow arming the system.
History / View History:
This allows viewing a
record of the tasks that users have performed
(disarm areas, bypass sensors, etc.)
PIN:
This allows the person who is logged in
to change their password.
Users:
This allows adding or deleting 'users'
from the system, or viewing or editing settings
for specific users.
A "User" is a person who has the authority to login to
system keypads, and/or to gain entry at access-
controlled doors.
Test:
This allows testing different aspects of
the system.
Config:
This allows a service user (person
with the service login ID and PIN) to set up a
new system, add devices to an existing
system, and/or view or change operational
settings for various items in the system.
Welcome
Enter ID: _
_
_
Your Name
Enter PIN:
_
_
_
_
Push
↓Stay ↓On
To Next Page
