Exploded view & dismantling sequence of parts
- 30 -
2. FR(D)180/S outdoor unit exploded view schedule
No. Description Remark
1 Top cover assembly
2 Air intake mesh assembly
3 Left panel assembly
4 Right panel assembly
5 Condenser
6 Capillary assembly
7 Manifold assembly
8 Valve Dg10
9 Motor support
10 Flat washer 5
11 Spring washer 5
12 Motor
13 Nut M5
14 Axial flow fan
15 Front panel assembly
16 Handle
17 Electric assembly
18 Cover plate
19 Baffle plate
20 Connecting pipe
21 Air exhaust pipe
22 Steam/water separator
23 Reversing valve assembly
24 Air suction pipe
25 Compressor junction box cover
26 Valve Dg19
27 Compressor
28 Damper ring
