CHUNLAN FRD23 - Special Main Parts;Wear Parts for Auxiliary Electric Heating

List of main parts & wear parts
- 60 -
2. List of main parts and wear parts of FR(D)71-B and FR(D)100-B
Size/Model
Symbol Description
FR(D)71-B FR(D)100-B
PCB1 Main control board ------ ------
PCB2 Wire controller ------ ------
PCB3 Remote controller ------ ------
RT1 Temperature sensor 3324 3324
RT2 Temperature sensor 3324 3324
RT3 Temperature sensor 3324 3324
C1 Capacitor
2.5μF/AC 450V
Indoor fan capacitance C1, C1’, 3μ
F/AC 450V
C1’ Capacitor
3μF/AC 450V
------
C3, C3’ Composite capacitor
35/3μF/AC 450V Startup capacitance 60μF/AC 450V
C4 Startup capacitor
100μF/AC 450V Parallel capacitance 50μF/AC 450V
PV Pressure switch YK-3.1/2.25 ------
M1 Outdoor fan motor YDK
5
120/30-6 YDK
1
120/45-6
C2 Capacitor ------
Startup capacitance 6μF/AC 450V
M2 Compressor Q2.2 ZR47K3-PFJ
M, M’ Indoor fan motor YDK110/30-4 YDK
5
110/30-4
FU Indoor fuse 5A 10A
FU Outdoor fuse 2A ------
YV Reversing solenoid valve DHF-6 STF-0408
KM AC contactor 3TF34 3TF3100 (single phase)
EH Heating band 40W ------
3. List of special main parts & wear parts of FRD71-B & FRD100-B aux. electric heating
Size/Model
Symbol Description
FRD71-B FRD100-B
PCB1 Main control board ------ ------
FT
1,2,3
1-time fuse
139℃ 15A 139℃ 15A
KT
1,2,3
Auto-reset thermal protector
KSD-A135℃ 10A KSD-A135℃ 10A
EH
1,2,3
PTC heater MZFR 2.3KW MZFR 2.3KW
XT1 Wiring terminal JXO-AB(600V 60A) JXO-AB(600V 60A)
XT4 Wiring terminal ------ ------
XT5 Wiring terminal ------ ------
K Small relay JQX-116F-L/220AL-2HS JQX-116F-L/220AL-2HS
