CHUNLAN FRD23 - List of Main Parts;Wear Parts of FR180;S and FR260;S

List of main parts & wear parts
- 63 -
6. List of special main parts/wear parts for FRD95 & FRD125/S aux. electric heating
Size/Model
Symbol Description
FRD95 FRD125/S
PCB1 Main control board ------ ------
FT
1,2,3(4,5,6)
1-time fuse
153℃ 10A 153℃ 10A
KT
1,2,3(4,5,6)
Auto-reset thermal protector
KSD-A135℃ 10A KSD-A135℃ 10A
EH
1,2,3(4,5,6)
PTC heater MZFR 1.5KW MZFR 1.5KW
XT1 Wiring terminal JXO-AB(600V 60A) JXO-AB(600V 60A)
XT4 Wiring terminal ------ ------
XT5 Wiring terminal JXW-Z
11
-02 JXW-Z
11
-03
KM1 AC contactor ------ 3TF3000
K Small relay JQX-116F-Z/220AL-2HS
7. List of main parts/wear parts of FR180/S and FR260/S
Size/Model
Symbol Description
FR(D)180/S FR(D)260/S
PCB1 Main control board ------ ------
PCB2 Wire controller ------ ------
PCB3 Remote controller ------ ------
RT1 Temperature sensor 3324 3324
RT2 Temperature sensor 3324 3324
RT3 Temperature sensor 3324 3324
C1, C2 Capacitor
CBB611A 6μF/AC 450V CBB65A-1 10μF/AC 450V
C, C’ Capacitor
CBB60F 10μF/AC 450V CBB65A-1 15μF/AC 450V
Communication line RF10AW/FG.000.01 ------
M3, M4 Outdoor fan motor YDK
5(6)
120/45-6 YDK145/60-8
M2 Compressor ZR81KC-TFD-522 ZR125KC-TFD-522
M, M’ Indoor fan motor YDK
2(3)
128/35-4 YDK
2,3
128/35-4
XT1 Wiring terminal seat JXW-2P JXW-2P
XT2 Wiring terminal seat JXW-05 JXW-05
XT3 Wiring terminal seat JXO-AB 600V 60A PBT660VAC 6mm
2
(4-place)
