5. Installation
5.1 Parts and function
Outdoor unit side (2 pipes)
Outdoor unit side (2 pipes)
Indoor unit side (2 pipes)
Indoor unit side (2 pipes)
Liquid Pipe (Ø9.52)
Liquid Pipe (Ø12.7)
Liquid Pipe (Ø12.7)
Liquid Pipe (Ø9.52)
Gas Pipe (Ø25.6)
Gas Pipe (Ø28.8)
Gas Pipe (Ø28.8)
Gas Pipe (Ø25.6)
AH1-280A
AH1-560A
5.2 Safety
•
I
f the connection kit is transferred to a new user, this manual shall be transferred to the user, together with the
conditioner.
•
B
efore installation, be sure to read Safety Considerations in this manual for proper installation.
•
T
he safety considerations stated below is divided into “ Warning” and “ Attention”. The matters on severe
accidents caused from wrong installation, which is likely to lead to death or serious injury, are listed in “
Warning”. However, the matters listed in “ Attention” are also likely causing the severe accidents. In general,
both of them are the important items related to the security, which should be strictly abided by.
•
A
fter the installation, perform test run to make sure everything is in normal conditions, and then operate and
maintain the connection kit in accordance with the user manual. The user manual should be delivered to the user
for proper keeping.
