APPENDIX Sensor resistance table
Model Code Description PCB socket Color Characteristic
AH1-280A
AH1-560A
0150401850 Ambient temp. sensor CN20 Green
R25=23KΩ±3%,
B25/50=4200K±3%
0150401849 TC1 sensor CN18 Green
R25=10KΩ±3%,
B25/50=3700K±3%
0150401848 TC2 sensor CN19 Black
R25=10KΩ±3%,
B25/50=3700K±3%
