page 12
Example of a PS10 label
gure A
WARNINGS
PRECAUTIONS FOR ASSEMBLY:
Fix the components using the holes formed in the box.
Replacement parts for this type of product must be identical to those being replaced.
If the power supply cable has a permanent connection to the power supply unit (see gure A) and is
damaged, in order to avoid any risks it must be replaced by the manufacturer, by its technical after-
sales service or a person with similar qualications.
IMPORTANT
Before connecting the socket to the mains supply, check that the feed voltage on the label corresponds
to that of the country of use.
Characteristics of transformer type: PS10
Technical characteristics:
Input voltage: 100-240 Vac
Input frequency: 50/60Hz
Output voltage: 29Vdc
Output current: 2A
Output connection:
Output cable: 8 cm with DC plug 5.5x2.5
Power supply unit: switching type
Device dimensions: 80 x 150 x 44.5 cm
-
+
