Assembly of Kit PS10BSA
1 - Device PS10BSA is used on the oor as an ancillary device and does not require
any installation (photo 1).
Warning
- Do not tread on the output connector or plastic casing and do not place any heavy objects on top.
1 - If the device is still connected, disconnect it.
2 - Overturn the device and position the bracket as shown
in photos 2 and 3, making sure that the holes on the
longest side correspond to those on the underside of the
casing.
photo 1
PS10BSA Floor version
PS10BSA Surface-mounted version
photo 2
photo 3
