Installation Handbook page 34 of 59 MANTA 50 – 80
TRANSMITTER CONNECTOR J1
10 pin Connector for local PC Serial Line connection (Mwatest or WAVE-
TEST SW )
Term Symbol Function
1-2-4-
6-8-10
N.C.
Not Connected
3
+13,8 Power Supply (13,8 V
) Converter interface RS-485/232
5
LO Low Line for RS 485
7
LH High Line for RS 485
9
GND Ground
TRANSMITTER CONNECTOR J2
Connector for MW oscillator (DRO)
Term Symbol Function
1
GND Ground connection for MW oscillator
2
DRO Modulation Frequency connection for MW oscillator
3
GND Ground connection for MW oscillator
TRANSMITTER CHANNELS SWITCH
N° Symbol Function
SW1
FUN Hexadecimal Modulation Channel Selector
TRANSMITTER NUMBER OF BARRIER SWITCHES SW2 SW3
N° Symbol Function
SW2
DEV 10 Barrier Number selector (tens column)
SW3
DEV 1 Barrier Number selector (units column)
TRANSMITTER LEDS
N° Symbol Function Default
6
D6 Fault indication.
OFF
5
D5 Tamper indication.
OFF
TRANSMITTER JUMPERS
N°
Symbol Function
Default
1
Jp1 RS485 Line termination (Jp1 position 1/2 = line
NOT terminated)
1/2
Closed
2
Jp2 Enable for FW download (Jp2 position 1/2 = FW
download NOT enabled)
1/2
Closed
3
Jp3
Internal Modulation signal (Tx-Master, Sync-Out
Jp3 = position 2/3) or External Modulation signal
(Tx Slave, Sync-In Jp3 = position 1/2)
OUT
2/3
Closed
