cias MICRO-RAY - User Manual

Questions and Answers

A
Andre ConwayAug 12, 2025
What to do if the Alarm LED is on for the cias MICRO-RAY Protection Device RX side?
- L
  Lisa RamirezAug 12, 2025
  If the Alarm LED is on for the RX side of your cias Protection Device, it could be due to several reasons. First, check for misaligned rays and perform the pointing procedure. Second, remove any obstacles present in the protected field. If these steps don't resolve the issue, the Tx or Rx circuit might be faulty and require replacement. Alternatively, the microwave front-end Rx or Tx could be faulty, needing replacement as well.
J
julie27Aug 19, 2025
How to troubleshoot a Fault LED on the Tx side of a cias MICRO-RAY Protection Device?
- A
  Angela JonesAug 19, 2025
  To troubleshoot a Fault LED on the Tx side of a cias Protection Device, begin by checking the power supply voltage, as it may be experiencing high or low voltage. Also, verify that the temperature is within the range of -35C° to +65C°. If these are not the cause, the oscillator in the Tx ray may have failed, requiring replacement of the Tx front end. As a last resort, the Tx ray itself may be faulty and need replacement.
M
Mary MendozaAug 27, 2025
What to do if the Faulty LED is switched on for the cias MICRO-RAY Protection Device RX side?
- C
  Cole HensleyAug 27, 2025
  If the Faulty LED is on for the RX side of your cias Protection Device, check the power supply voltage to ensure it's not too high or too low. Also, verify that the temperature is within the prescribed range of -35C° to +65C°.
B
Brian ThorntonSep 4, 2025
Why is the Tamper LED on for my cias MICRO-RAY Protection Device?
- J
  Julie HensleySep 4, 2025
  The Tamper LED might be on because the microswitch is open. You should check the microswitch closure.

cias MICRO-RAY Specifications

General

Detection Range	Up to 100m
Number of Beams	4
Protection Class	IP65
Material	Polycarbonate
Alarm Output	Relay output NC/NO
Tamper Output	NC
Humidity Range	Up to 95% non-condensing
