6 FEATURES
Technical Features
TECHNICAL SPECIFICATIONS
Min
Nom
Max
Notes
Operating frequency:
F5
24 GHz
-
24,25 GHz
Maximum power:
F5
-
-
100 mW
e.i.r.p.
Modulation
-
Pulsed
-
On/off
Duty-cycle
-
50/50
-
-
Number of channels
-
-
16
-
Ranges:
MICRO-RAY range
-
100 m
-
Power supply voltage (V )
11.5 V
13.8 V
16 V
-
Single TX module supply current in supervision
(mA )
-
65
-
-
Single RX module supply current in supervision
(mA )
-
53
-
-
Intrusion alarm contact (RX)
-
-
100mA
C-NC
Tamper contact (TX + RX)
-
-
100mA
C-NC
Fault contact (TX + RX)
-
-
100mA
C-NC
Light indicators:
Intrusion alarm (RX) Red LED off
-
-
-
Sleep
Tampering (TX+RX) Red LED off
-
-
-
Sleep
Fault (TX+RX) Red LED off
-
-
-
Sleep
Adjustment of thresholds
-
-
-
Onboard
1m Column Weight (2 rays)
-
6000 g
-
-
2m Column Weight (3 rays)
-
11000 g
-
-
3m Column Weight (4 rays)
-
17000 g
-
-
Column diameter
-
180 mm
-
-
Operating temperature
-35 °C
-
+65 °C
-
Performance level
4°
Degree of enclosure protection
IP55
