CIAT PowerCiat LX ST User Manual

EN-23 POWERCIAT LX ST/HE/XE
4.3 - Compressor electrical data
Compressor I Nom
(1)
I Max
(Un)
(2)
I Max
(Un - 10%)
(3)
LRYA
A
(4)
LRDA
A
(5)
Cos
Phi nom.
(6)
Cos
Phi Max.
(7)
06TSA155 64 93 99 170 530 0,87 0,9
06TSA186 80 111 118 170 530 0,86 0,89
06TTA266 117 162 172 303 945 0,86 0,9
06TTA301 132 177 188 388 1210 0,87 0,9
06TTA356 153 207 220 388 1210 0,87 0,9
06TUA483 225 292 311 587 1828 0,87 0,88
06TUA554 241 338 360 587 1828 0,88 0,89
06TVA680 302 400 436 629 1919 0,87 0,89
06TVA753 315 430 468 629 1919 0,88 0,89
06TVA819 347 465 496 629 1919 0,88 0,89
Key
(1) Nominal current draw at standard Eurovent conditions (see denition of conditions under nominal unit current draw)
(2) Maximum operating current
(3) Maximum compressor operating current, limited by the unit (current given for maximum capacity at 360 V)
(4) Locked rotor current for star connection (connection during compressor start-up)
(5) Locked rotor current for delta connection
(6) Value at standard Eurovent conditions: evaporator entering/leaving water temperature 12°C/7°C, condenser entering/leaving water temperature 30°C/35°C.
(7) Value at maximum capacity and nominal voltage
4.4 - Compressor usage per circuit (A, B, C, D)
Compressor Circuit 0808 0908 1008 1108 1358 1528 1858 2008 2158 2308 2528 2628 3028 3428 3828 4008 4408 4608
06TSA155
A 1
B 1 1 1
06TSA186
A 1 1
B 1 1 1
06TTA266
A 1
B
06TTA301
A 1
B 1 1
06TTA356
A 1 1 1
B 1 1 1
06TUA483
A 1 1 1 1
B 1
06TUA554
A 1 1 1
B 1
06TVA680
A 1
B
06TVA753
A 1
B 1 1
06TVA819
A 1
B 1 1 1
4 - PHYSICAL PROPERTIES AND ELECTRICAL DATA FOR LX UNITS
