CIAT PRO-DIALOG+ - ALARMS Menu Functions

4.9.10 - ALARMS menu
NAME DESCRIPTION
ALARMRST Alarm reset
CUR_ALRM Current alarms
ALMHIST1 Alarm history
4.9.11 - CONFIG menu
NAME DESCRIPTION
GEN_CONF General configuration menu
PUMPCONF Water pump configuration menu
HC_CONFIG Heating/cooling configuration menu
RESETCFG Reset configuration menu
USERCONFIG User configuration menu
SCHEDULE Time schedule
HOLIDAY Holiday calendar
BRODCAST Broadcast menu
DATETIME Date and time menu
DISPLAY Display configuration menu
CTRL_ID Identification control
4.9.12 - ALARMRST menu
NAME FORMAT UNIT DESCRIPTION
RESET_AL Normal - Alarm reset
ALM Normal - Alarm status
alarm_1c nnnnn - Current alarm 1
alarm_2c nnnnn - Current alarm 2
alarm_3c nnnnn - Current alarm 3
alarm_4c nnnnn - Current alarm 4
alarm_5c nnnnn - Current alarm 5
alarm_1 nnnnn - Current JBus alarm 1
alarm_2 nnnnn - Current JBus alarm 2
alarm_3 nnnnn - Current JBus alarm 3
alarm_4 nnnnn - Current JBus alarm 4
alarm_5 nnnnn - Current JBus alarm 5
4.9.13 - CUR_ALRM menu
This menu lists up to ten active alarms. For each alarm the
display shows the time and date the alarm was generated as
well as the alarm description. Each screen shows one alarm.
…\ALARMS\CUR_ALM
HH:MM DD-MM-YY: alarm text
Alarm #1
4.9.14 - ALMHIST1 menu
This menu lists up to twenty alarms that have occurred at the
unit. For each alarm the display shows the time and date the
alarm was generated as well as the alarm description.
Each screen shows one alarm.
…\ALARMS\ALMHIST1
HH:MM DD-MM-YY: alarm text
Alarm #1
