EN - 10
*Control by Water/Application G
Electric stage used as main stage
*Control by Water/Application H
Electric stage used as additional stage
N.B.: this configuration must only be used with hot water with a temperature < 50°C to prevent any risk of the
appliance overheating.
N.B.: this configuration must only be used with hot water with a temperature < 50°C to prevent any risk of the
appliance overheating.
Valve C Valve F
Hot water
C F
Water at neutral temperature
C F
Cold water
C
F
Valve C Valve F
Hot water
C F
Water at neutral temperature
C F
Cold water
C F
Battery, coil
*Control by Water/Application I
Electric stage used as main stage + additional
Valve C Valve F
Hot water
C F
Water at neutral temperature
C F
Cold water
C F
Battery, coil
Battery, coil
Battery, coil
Battery, coil
Battery, coil
