Cimon CM1-XP1U User Manual

- 14 -
Item
Specification
CM1-CP3E CM1-CP4E CM1-CP4F
Program Control Method Repetitive operation, Stored Program (ROM mode), Periodic operation
I/O Control Method
Scan synchronous batch processing system (I/O refresh), Indirect meth
od, Direct method by instruction
Program Language
IL (Instruction List), LD (Ladder Diagram),
FBD (Function Block Diagram), FBD Extension,
SFC (Sequential Function Chart)
Number of Instructions Basic Instruction: 60, Application instruction: 480
Data
Processing
LD 0.084 μs/step 0.2 μs/step
Program Memory 512 Kbyte 256 Kbyte
Number of
Program Block
s
Max 128, up to 65,530 steps per block (PID)
Number of I/O 1,536 384
Number of I/O Devices 32,768 8,192
Supporting
Program
LD
Scan, Subroutine, Initialize (COLD), Initialize (HOT), Periodic interrupt
Special
Configuration
Initializing special card, PID control, Thermistor setting, Loadcell setting,
I/O Input module filter setting
Communication
User protocol (Serial), User protocol (Ethernet), MODBUS TCP/RTU Ma
ster, Ethernet High-speed link, CIMON-NET Master / Slave, DNP3, Publ
ic network IP setting, Fieldbus, OPC UA Server
SFC SFC Program
Periodic Interruption
Maximum 15, cycle setting (10
–
60,000
ms, Unit :10
ms),
priority setting (0
–
14)
Base Expansion
Maximum 16 (10Base-T) -
Max. Distance Electricity (100 m) -
Redundancy -
Operation Modes LOCAL/Remote (RUN, STOP, PAUSE)
Restarting Cold, Hot Restart
Self-Diagnosis
Monitoring delay of processing, problems of memory,
I/O, battery, power error
Data Preservation
Against Power Failure
K device and conservation (Latch) in M, L, T, C, S, D device
Watch Dog Timer (WDT)
Maximum 5000 ms (Unit: 10 ms)
Timer
On Delay, Off Delay, Addition, Monostable, Retriggerable
Cycle: Either 10 or 100 ms
TC (Current value)/TS (Setting value)
Counter
UP, DOWN, UP/DOWN, RING COUNTER,
CC (Current value)/CS (Setting value)
No limitation on number of points
Count range: -32,768–32,767
PID
32 Channels, Auto-Tuning
Performance Specification (CP Series)

Cimon CM1-XP1U Specifications

General

Brand	Cimon
Model	CM1-XP1U
Category	Controller
Language	English
