Cimon CM1-XP1U User Manual

- 15 -
Communication
Channels
USB
USB 2.0 B Mini-B: For Loader Protocol
Serial
RS-232C (Maximum 38,400 bps):
CICON Loader, CIMON-HMI,
MODBUS RTU Slave / Type: Terminal Block
RS-485 (Maximum
115,200 bps):
CICON Loader, CIMON
-HMI, MODBUS RTU Sl
ave / Type: RJ45
Ethernet
Expanded: 10Base-T
-
Event log Power, Mode, Error
Firmware Upgrade Available
Power 5 Vdc, 195 mA 5 Vdc, 70 mA 5 Vdc, 100 mA
Weight (g) 140 g 127 g 137 g
Floating-point Arithmetic -
Capacity of
Scan
P
rogram
64k steps 16k steps
Device
Memory
X
1,536 384
Y
1,536 384
M
8,192
K
2,048
L
2,048
F
2,048
T
1,024 (select between 10 ms and 100 ms)
C
1,024
S
100 Card*100 Step
D
10,000 Word 5,000 Word
Z
1,024 Word
Q
512 Word
R
16 Word
Performance Specification (CP Series)
